Node Dimensions - Visual Measurements for Blender using Geometry Nodes

[Click here for Free PDF and Video Documentation]
Simply enter "0" to receive the documentation link in your inbox.

Add CAD-Style Distance, Radius, and Angle Measurements to Your Mesh in Blender

Enhance your 3D projects with precise Geometry Nodes dimensions powered by Python. Pre-animated, unit-convertible, and compatible with technical fonts. Perfect for creating accurate, editable measurements in any scene. Fast. Precise. Professional.

• What Are Node Dimensions?
• The Story Behind the Product
• Three Geometry Node Dimension Tools
• Measure Distance
• Measure Radius
• Measure Angle
• All dimensions support animation (with auto-added keyframes)
• Customizable colors with unique materials per dimension type
• Compatible with custom fonts
• Popup + modifier panels for complete control
• Supports comma decimals and additional text labels
• Dimensions automatically follow source mesh vertices
• No need to apply scale - dimensions update dynamically
• Geometry Nodes auto-generated via Python
• One-click thick wireframe option
• Toggle background: white or blueprint blue
• Auto-adjusting text color for optimal contrast
• Works in both Cycles and Eevee
• Built entirely with Geometry Nodes and Python
• For personal and commercial use
• Includes detailed PDF documentation
• 30-day refund guarantee
• Responsive support
• Multi-platform support (macOS, Linux, Windows)
• Free lifetime updates
• About the Creator
• Final Notes

What Are Node Dimensions?

Node Dimensions are ready-to-use, customizable measurement tools that add professional Distance, Radius, and Angle indicators to your Blender scenes using Geometry Nodes and Python.

Whether you're working on product designs, architectural models, or technical animations, these dimension overlays provide clear measurements without requiring manual setup.

With just a few clicks, add polished CAD-style annotations that remain editable, animatable, and automatically update with your geometry - saving time while enhancing your presentation.

The Story Behind the Product

As Geometry Nodes revolutionized Blender's procedural workflow, one gap remained: precision measurement tools.

This product fills that void by bringing accurate Distance, Radius, and Angle measurements into your workflow through Geometry Nodes and Python automation. It bridges creative design with technical precision, offering clean, animated dimensions that stay connected to your geometry.

Whether you're creating engineering visuals, architectural presentations, or simply need better spatial reference, Node Dimensions gives Blender the precision tools you've always wanted.

Three Geometry Node Dimension Tools

Includes specialized Distance, Radius, and Angle measurement systems built with Geometry Nodes. Each tool delivers precision and clarity for CAD-style annotations, technical visualizations, and procedural workflows.

Measure Distance

Create precise distance measurements between points with customizable arrows. Choose from 3 arrow styles and 6 units (mm, cm, m, inch, ft, yd). Ideal for technical annotations and scale references.

Simply select 2+ vertices in Edit Mode to generate measurements. The system automatically creates instances between each vertex pair (A,B,C becomes A-B and B-C). Closed shapes generate complete perimeter measurements (A,B,C,D becomes A-B, B-C, C-D, D-A).

Measure Radius

Instantly visualize radii for circular meshes or arc segments. Perfect for rounded geometry and curves in engineering models. Delivers clean, scalable measurements for CAD-style presentations.

Select 3 vertices in Edit Mode to generate Radius/Diameter measurements.

Measure Angle

Select any mesh, then choose 3 vertices in Object Mode (via cursor selection) to calculate angles.

Display angular relationships with clean arc visuals and precise values. Excellent for mechanical designs, rigging setups, or architectural plans. Snaps to vertices and updates dynamically.

Key Features

Animatable Dimensions
All measurements support animation with auto-keyframing. Perfect for demonstrating transformations, morphs, or technical animations.

Customizable Colors

Each dimension type has dedicated emission-based materials for easy color customization. Maintain visual organization in complex scenes.

Font Flexibility
Use any font or choose from built-in technical options (ISOCP & ISOCPEUR). Achieve authentic blueprint or CAD styling instantly.

Complete Control

Access all settings via popup panels or modifiers. Adjust units, font size, colors, labels and more without navigating node trees.

Smart Formatting

Supports comma decimals and additional text labels (e.g., "Length: 2.5m").

Automatic Updates
Dimensions stay locked to source vertices, updating in real-time with any transformation. Your original mesh remains untouched.

Scale-Friendly
Works perfectly with non-uniform scaling - no need to apply transforms.

Efficient Generation
All node setups are automatically created via Python - no manual node work required.

Enhanced Visibility

• One-click thick wireframe overlay
• Toggle between white and blueprint backgrounds
• Auto-contrasting text for optimal readability

Render Ready
Works flawlessly in both Cycles and Eevee. Performance-optimized with low-poly meshes and emission shaders.

Built with Geometry Nodes

All dimension visuals are created using Blender's Geometry Nodes, with Python automating the setup process.

New to Geometry Nodes? Start with Blender's official introduction:
Geometry Nodes Basics

Unlimited Customization

Every element is adjustable - colors, sizes, fonts, and positioning can all be fine-tuned to match your project's needs.

Licensing Options

For Personal and Commercial Use
Use freely in both personal projects and professional work.

1. Pro - Single Seat: Full license for individuals/freelancers (personal + professional use)
2. Pro - Multi Seat: Studio license for unlimited users within one company

Asset Licensing:
Posters, trailers, videos, and PDF tutorials fall under the Standard Royalty Free License:
Learn More

Python Add-on:
Released under GPL 3.0 License:
View License

Complete licensing details included in download package.

Comprehensive Documentation

Prefer written guides? The included PDF documentation lets you quickly find information without watching lengthy tutorials.

Risk-Free Purchase

30-Day Refund Guarantee
Gumroad offers full refunds within 30 days - no questions asked.

I recommend trying the free documentation first to evaluate the tool.

Need Help?
Contact me directly:

• Gumroad support inbox
• Email: jugaadanimation@gmail.com

If any issues arise, Gumroad can process refunds.

Reliable Support

Questions or technical issues? I'm always available:

• Gumroad support inbox
• Email: jugaadanimation@gmail.com

Cross-Platform Compatibility

Fully supports Windows, macOS, and Linux.
Fun fact: This tool was developed on Ubuntu Linux, where Blender often runs fastest!

Lifetime Updates

All future upgrades and improvements will be included for free for existing customers.

Note: Price may increase in future versions - purchasing now locks in your access to all upcoming features.

About the Creator

Hi! I'm Vikrant Jadhav - motion graphics artist and creator behind Blender Renaissance.

My previous add-on "Node Charts: Info Graphs For Blender Using Geometry Nodes" has:

• Sold 150+ copies
• Earned eight 5-star ratings and one 4-star review

With over 10 years of professional Blender experience, I've created explainer videos and app promos for clients worldwide (US, Spain, India, New Zealand).

Why I Created This Tool

When I required technical measurements in Blender, no Python-based Geometry Nodes solution existed. So I built Node Dimensions to:

• Quickly add editable, precise markers (distance/radius/angle)
• Work entirely within Geometry Nodes
• Streamline my technical animation workflow

I believe it will revolutionize your workflow too.

Ready for CAD-Style Dimensions in Blender?
Get Node Dimensions Now.

Best regards,
Vikrant Jadhav
Blender Renaissance
